5.8 EXTENDED BACK REST
This option offers extra support and comfort to the upper
back and shoulders. It is particularly suited to taller users,
(Fig 5.21).
5.9 HEAD REST
The crash tested head rest offers additional support and
comfort to the back of the head, neck and shoulders,
(Fig.5.22).
5.10 REAR UNIVERSAL MOUNT
This mount is used for the rear storage box, but it can
also be used as a base to strap small items of luggage to,
(Fig.5.23).
WARNING!
Maximum Carrying Load = 10kg.•
The weight of the driver plus any luggage, should not •
exceed the maximum user weight of the scooter.
5.6 POWER USB OUTLET 5V- D.C.
This socket provides a convenient d.c. 5V - 1.2A power
supply to run low-current external accessories such as
phone chargers etc. (Fig.5.19).
WARNING!
Do not connect appliances that exceed the current rating
of the power outlet socket. The power will be cut if 1.2A
is exceeded, but will automatically be restored when the
abnormal current load is removed.
5.7 RAISED FOOT PLATFORM
This is to facilitate the correct knee / leg angle to obtain
maximum comfort for users with shorter lower leg
lengths, (Fig.5.20).
WARNING!
Be aware of the extra height from the ground and take
care when getting on and off the scooter.
Fig.5.19
Fig.5.20
Fig.5.21
Fig.5.22
Fig.5.23
