4.24 SAFETY CHECKS
WARNING!
The scooter rider plus items should never exceed a •
total weight of 175 kg.
Before you use the scooter, check that it is not in •
freewheel and that all of the controls are functioning
correctly.
If you discover any scooter malfunction, take it to be •
repaired or reset. Your dealer can help you to find the
fault and correct it.
Make sure batteries are charged. Do not use the •
scooter when battery is low. The scooter may come
to a sudden, unexpected stop.
Be aware that there is a point during every transfer •
when the scooter seat is not below you.
Use extra care when you drive your scooter in •
reverse. If one of the wheels hits an obstacle, you
could lose control of the scooter or fall out.
Never use your scooter on a slope unless you are •
sure you can do so without losing traction.
When travelling along, always ensure the backrest is •
upright and the seat faces forwards.
Lift the scooter only by non-detachable parts of the •
main frame.
Never short-circuit electrical connections as you •
could cause an explosion.
Do not use the scooter if any of the tyres are •
damaged or under/over-inflated.
When using mobile phones you should switch the •
scooter off.
Do not smoke whilst on-board the scooter.•
If you take a break from driving, but remain seated in •
the scooter for more than just a moment, switch the
scooter off at the ignition key.
5.0 Assembly & Options
5.1 SEAT ADJUSTMENTS
WARNING!
Observe correct lifting techniques at all times when
lifting components over 10kg.
Flip Up Armrests (Fig 5.1): By pulling up on the end of
either armrest, the armrest will flip back for easy transfer
on and off of your Elite2.
Seat Rotate Lever (Fig 5.2): This is found under the left
side of the seat. Push it forwards to allow the seat to
rotate 360 degree and release to lock in any 45 degree
position desired.
Seat Height Adjustment: (Fig 5.3) The seat post is
height adjustable, providing 4 height positions. Carefully
unscrew the 2 bolts and nuts, and insert into desirable
position and tighten nut.
Sliding Mechanism (Fig. 5.4): This allows forward and
backward movement of the seat. Pull up lever found
under the front of the seat and use legs and body to
move to the required position and release lever.
Fig.5.1
Fig.5.2
Fig.5.4
Fig.5.3
