15.0 Specification Sheets (EN 12184 & ISO 7176-15)
Sunrise Medical Logistics BV Operating temp: -25degC to 50DegC
Groningenhaven 18-20, 3433 Storage temp: -40degC to 65degC
PE ,Nieuwegein, Netherlands Moisture resistance: IPX4
T: +31 (0)30 - 60 82 182 Customer Service No restrictions on humidity and air pressure
F: +31 (0)30 - 60 55 880
www.sunrisemedical.com
MODEL: STERLING ELITE2 XS, RS
Maximum occupant
mass: 175 kg
The Sterling Elite2 XS, RS
conforms to the following
standards:
a) requirements and test
methods for static, impact
and fatigue strengths (ISO
7176-8)
b) power and control
systems for electric
wheelchairs requirements
and test methods (ISO
7176-14)
c) climatic test in accor-
dance with ISO 7176-9
d) requirements for resi-
stance to ignition in accor-
dance with ISO 7176-16
e) the product is specified
as a Class C power pro-
duct
f) all materials used on this
product conform to EN1021
parts 1 and 2
NOTE: Measurments of
upholstered parts are
approximate. All other
measurments may be
subject to change
ISO 7176-15 MIN. MAX. COMMENTS
Overall length 1390mm 1390mm standard configuration
Overall width 670mm 670mm standard configuration
Total mass (with batteries) 132kg 132kg standard configuration
Mass of the heaviest part - 23kg 72 Ah Battery
Static stability downhill - 15° 175kg User
Static stability uphill - 15° 175kg User
Static stability sideways - 15° 175kg User
Energy consumption (max. range) - 44km To ISO 7176-15
Dynamic stability uphill - 10°-18% 175kg User
Obstacle climbing - 100mm standard configuration
Ramp transition 8° 8° without high centring
Max. speed forward 15kph standard configuration
Min. brake distance from max. speed - 4.5m with standard programming
Max. speed reverse - 50% % of forwards speed
Effective seat depth 460mm standard configuration
Effective seat width 475mm standard configuration
Seat surface height 440mm 540mm to scooter floor
Back rest angle -45° +45° from vertical
Back rest height 510mm standard configuration
Fore / aft seat adjustment -80mm +80mm from centre position
Seat weight with slide 22kg standard configuration
Top of arm rest to seat 80mm arm rest set at 90°
Min. turning radius 1400mm standard configuration
Min. turn between walls 1850mm standard configuration
Nominal battery voltage 24V 24V two 12V batteries
Reversing width 1600mm -----------
Controller cut-off voltage 16V drive stops
Battery capacity 60Ah 72Ah see options
Battery fusible links - 150A In-line fuse on each battery
Battery charger loom fusible link - 15A
Battery charger 8A 10A automatic cyclic
Max. kerb height 100mm
Ground clearance 110mm
Rear suspension travel 50mm Unladen
Front suspension travel 25mm Unladen
Rear wheel drive - - 3 wheel scooter
Scooter push force 100N in freewheel
Crash tested YES Test to 7176-19
Tyre Pressure 1.8-2.0 bar, (25-28 P.S.I.)
