Sterling Elite
2
XS-RS-Plus
7.0 Scooter Control System
7.1 ELITE
2
XS, RS CONTROL SYSTEM
Fig.7.1
7.1.2 CONTROL LEVER
7.1.7 MODE BUTTON
7.1.6 LIGHTS
7.1.5 INDICATORS
7.1.4 HAZARD LIGHTS
7.1.3 HORN
7.1.9 BATTERY LEVEL GAUGE
7.1.10 LCD DISPLAY
7.1.8 SPEED CONTROL
Fig.7.1.1
7.1.1 KEY SWITCH
CHARGER SOCKET
TILLER
ADJUSTER
7.1.10A DIRECTIONAL ARROW
