56
FIG. D CONTROL BOX
FIG. D BEDIENINGSKAST
FIG. D SCHALTKASTEN
FIG. D BOITE DE COMM ANDE
INDEX REFERENCE DESCRIPTION
03-700-650 Control box assy.
1 69-141-041 Contact block
2 69-141-061 Emergency stop
3 69-900-045 Keyboardprint
4 69-302-021 Box
5 69-120-002 Main switch 16A 4P
6 69-900-040 Printed circuitboard
7 69-206-001 Fuse 630 mAT
8 69-202-004 Acoustical alarm
9 3501.50.90.03 Motor relay
10 69-302-023 Hinge set
11 69-900-041 Additional print traffic lights inside building (OPTION)
