stertil COMBILOK - Page 62

58
FIG. F SAMENSTELLING HYDRAULIEK
FIG. F ZUSAMMENBAU HYDRAULIK
FIG. F ASSEMBLAGE HYDRAULIQUE
FIG. F
ASSEMBLY HYDRAULIC
DESCRIPTION
H.D. Hose Long OUT (A) 11400
H.D. Hose Long IN (B) 8150
H.D. Hose Lat IN (A) 11550
H.D. Hose Lat OUT (B) 11550
H.D. Hose Lat IN (A) 7680
H.D. Hose Lat OUT (
B) 7680
Elbow W 6
-PL
Straight adaptor GE 6
-PL/R1/4"
Straight adaptor GE 10
-PL/R3/8"
Elbow EVW 10
-PL
REFERENCE
03
-705-541
03
-705-542
03
-705-543
03
-705-545
03
-705-544
03
-705-546
68
-700-106
68
-700-410
68
-700-420
68
-703-003
INDEX
1
2
3A
3B
4A
4B
5
7
8
9
