Description of operating
Extraction limit (by operating time)
To activate
Jumper (J1) may not be setted, close the windows! Press the switches “Open” and “Closed” (STOP) at the vent switch
as long as the display “open” is ashing fast. Open the motor with the switch “open” up to the position required within the
next 10 sec. (otherwise the extraction limit is not activated!) and stop the motor in this position with the switch “closed”.
If no other switch is pressed within the next 10 sec. the extraction limit is activated, the learning phase is nished.
If the extraction limit is activated and the actuator is not closed, it is signalised by double ashing at the “open” display.
Note: the extraction limit and the ventilation function is cut off for 3 min. after SHE activation and following reset.
To deactivate
Press the switches “open” and “closed” (STOP) at the vent switch as long as the display “open” is ashing fast. If no
other switch is pressed within the next 10 sec. until the ashing goes out the extraction limit is deactivated.
Note: in case of mains or battery failure or SHE activation the function is out of order. In case of mains or
battery failure, the windows close immediately.
LED display
In the SHE control panel and SHE manual call points.
The green LED display
OK
- operating OK - is shining. It goes out in case of:
- mains or battery failure
- malfunction of the line monitoring of the connected drives, automatic detectors or SHE manual call points.
The yellow LED display
- malfunction - is ashing in case of: malfunction, cable connection defective, mains and/or
battery failure.
Attention: If any malfunction is indicated the malfunction has to be eliminated immediately. The perfect
function of the system is not longer guaranteed.
The red LED display - SHE activation - is shining in case of: manual or automatic SHE activation.
Possible connections
- 4 linear drives 24 V DC with integrated electronic power cut-off, or
- 4 chain motors with limit switches (overall power consumption of all motors connected: max. 4 A)
- 10 SHE manual call points RBH/3A...
- 6 automatic detectors with 2-wire-technology, optical smoke detectors and/or detectors of heat differential and/or
detectors of maximum heat
- 10 external vent switches Open/Stop/Closed (e.g. type LTA 25)
Extensions via optional modules
TRZ/WRMAS Basic (Wind rain detector alarm malfunction). To connect max. 1 wind/rain detector (type WRM 24V) or
rain sensor (type RS) and potential free trans-mission of the signals Alarm (SHE activated) and malfunction collection
(max. 24 V / max. 0.5 A).
