Technical datas
The power supplies and electrical control equipment are to be operated exclusively with the components authorised by
the manufacturer.
Electrical properties
Primary energy supply
Operating voltage supply: 230 V AC / 50 Hz, (±10 %), separately fused
Current consumption: approx. 150 VA
Power consumption mains: max. 1 A
Monitoring: yes, Software monitoring
Terminal: screw terminals max. 2.5 mm²
Fuse: F1 mains fuse: T 1A H
Secondary energy supply
Batteries: 2 x 12 V / 2 Ah monitor funct. for low voltage wire breakage and fuse failure,
service life 4 years
Battery type: lead gel battery with VdS certications
Emergency power: 72 h
Charging time: 20 h for emergency power
Terminal: connecting cable and at-pin plug
Monitoring: yes, cyclical
Fuse: F3 battery fuse: FKS 5A
Output
Voltage: 24 V DC (nominal) (-15 % / +25 %), ltered
Ripple: <1
Power (nominal): 4 A 10 % ED (referring to 30 min)
Power (temporary): 2.6 amp (≤600 ms)
Opening / closing sequence: reversal of voltage polarity
Pause time during change of
polarity: 200 ms
Timing in accordance with
prEN 12 101-9: yes, alteration of direction of travel every 2 min
Automatic activation: after 3 min
Cable monitoring function: linear drives (with 3rd monitoring lead combined with monitoring diodes)
Terminal: max. 1.5 mm², screw terminal
Fuse: F2 motor fuse, FKS 5A
Call point output
Voltage: 24 V nominal
Power: max. 60 mA, 100 % ED
Terminal: max. 1.5 mm², screw terminal
max. Pieces: 10
Emergency power: yes
Automatic alarm unit output
Voltage: 24 V nominal
Power: max. 150 mA, 100 % ED
Terminal: max. 1.5 mm², screw terminal
Cable monitoring function: end resisted 10k
max. Pieces: 6
Emergency power: yes
SHE control panel TRZ Basic 4A/UP
