OPERATION
Menu structure
10 |WPF | WPF cool www.stiebel-eltron.com
5. Menu structure
After activating the programming unit, you can use the scroll
wheel to select other operating modes or the menu key to jump
to a level from which you can navigate to a specific appliance
parameter.
Level 1 Level 2
INFO SYSTEM
HEAT PUMP
DIAGNOSIS SYSTEM STATUS
HEAT PUMP STATUS
SYSTEM
INTERNAL CALCULATION
FAULT LIST
RELAY TEST SYSTEM
PROGRAMS HEATING PROGRAM
DHW PROGRAM
PARTY PROGRAM
HOLIDAY PROGRAM
HEAT-UP PROGRAM
SETTINGS GENERAL
HEATING
DHW
COOLING
COMMISSIONING ENTER CODE
LANGUAGE
SOURCE
HEATING
DHW
COMPRESSOR
EMERGENCY OPR
HEAT PUMP RESET
FAULT LIST RESET
SYSTEM RESET
5.1 INFO MENU
In the INFO menu you can check comparisons of set and actual
values for temperatures, flow rates and pressures of the heating
system and the heat pump.
Note
Please note that actual and set values can only be dis-
played if the appropriate sensors are connected.
5.1.1 INFO SYSTEM
Level 3
Room temperatures
ACTUAL TEMPERATURE FE7
Actual room temperature for heating circuit 1 (HC1) or heating circuit
2 (HC2)
(will only be displayed if the FE7 remote control is connected)
°C
SET TEMPERATURE FE7
Set room temperature for heating circuit 1 or heating circuit 2
(will only be displayed if the FE7 remote control is connected)
°C
ACTUAL TEMPERATURE FEK
Actual room temperature for heating circuit 1 or heating circuit 2
(will only be displayed if the FEK remote control is connected)
°C
SET TEMPERATURE FEK
Set room temperature for heating circuit 1 or heating circuit 2
(will only be displayed if the FEK remote control is connected)
°C
REL HUMIDITY %
DEW POINT TEMPERATURE
Dew point temperature (will only be displayed if the FEK remote con-
trol is connected)
°C
Heating
OUTSIDE TEMPERATURE °C
ACTUAL TEMPERATURE HC 1
Actual heating circuit temperature heating circuit 1
°C
SET TEMPERATURE HC 1
Set heating circuit temperature heating circuit 1 (HC1). Fixed temper-
ature is displayed with set value control.
°C
ACTUAL TEMPERATURE HC 2
Actual heating circuit temperature heating circuit 2
°C
SET TEMPERATURE HC 2
Set heating circuit temperature heating circuit 2 (HC2). Fixed temper-
ature is displayed with set value control.
°C
ACTUAL FLOW TEMPERATURE HP
Actual heat pump flow temperature
°C
ACTUAL FLOW TEMPERATURE BH
Actual flow temperature of electric emergency/booster heater
°C
ACTUAL RETURN TEMP °C
SET FIXED TEMPERATURE °C
ACTUAL BUFFER TEMPERATURE
Actual buffer cylinder temperature
°C
SET BUFFER TEMPERATURE
Set buffer cylinder temperature
°C
HEATING PRES bar
FLOW RATE l/min
SYST FROST PRO
System frost protection temperature
°C
DHW
ACTUAL TEMPERATURE
Actual DHW temperature
°C
SET TEMPERATURE
Set DHW temperature
°C
FLOW RATE l/min
To Next Page
