13.4 WPM3i commissioning report
The following lists the parameters that can be adjusted via the programming unit.
Programs / heat-up program Setting range Standard System value
LOW END TEMPERATURE 20..40 °C 25.0°C
TEMP. RISE PERIOD 0 to 5 days 2 days
MAXIMUM TEMPERATURE 20...50°C, inc 0.5K 40.0°C
MAX TEMPERATURE DURATION 0 to 10 days 0 days
RISE PER DAY 1 to 10 K/day 1 K/day
Settings / general Setting range Standard System value
CONTRAST 01 to 10 5
BRIGHTNESS 0 to 100 % 50 %
TOUCH SENSITIVITY 01 to 10 04
TOUCH ACCELERATION 02 to 10 06
Settings / heating / heating circuit 1 Setting range Standard System value
COMFORT TEMPERATURE 5 to 30 °C 20 °C
ECO TEMPERATURE 5 to 30 °C 20 °C
MINIMUM TEMPERATURE OFF / 10 to 20 °C OFF
HEATING CURVE RISE 0.2 to 3 0.6
HEATING CURVE VIEW
Settings / heating / heating circuit 2 Setting range Standard System value
COMFORT TEMPERATURE 5 to 30 °C 20 °C
ECO TEMPERATURE 5 to 30 °C 20 °C
MINIMUM TEMPERATURE OFF / 10 to 20 °C OFF
MIXER DYNAMICS 20 to 90 °C 50 °C
HEATING CURVE RISE 30 to 240 100
HEATING CURVE RISE 0.2 to 3 0.2
HEATING CURVE VIEW
Settings / heating / standard setting Setting range Standard System value
BUFFER OPERAT ON / OFF OFF
SUMMER MODE ON / OFF ON
OUTSIDE TEMPERATURE 3 to 30 °C 20°C
BUILDING HEAT BUFFER 1 to 3 1
MAXIMUM RETURN TEMP 20 to 60°C 60°C
MAXIMUM FLOW TEMP 20 to 65°C 65 °C
FIXED VALUE OPERATION OFF / 20 ..50 °C OFF
OPTIMUM HEATING CURVE OFF / 0.01 ..0.1 OFF
FROST PROTECT -10 to 10°C 4°C
Settings / heating / FE7 remote control Setting range Standard System value
HEATING CIRC PRESELECTION 1 / 2 heating circuits Heating circuit 1
ROOM INFLUENCE OFF / 0 to 20 5
ROOM CORRECTION -5 to 5 K 0
Settings / heating / pump cycles Setting range Standard System value
PUMPCYCLES ON / OFF OFF
Settings / heating / electric reheating Setting range Standard System value
DUAL MODE TEMP HEATING -40 to 40°C -20°C
LOWER APP LIMIT HEATING OFF / -39.5 to 40°C -20°C
Settings / DHW / DHW temperatures Setting range Standard System value
COMFORT TEMPERATURE 10 to 60°C 50 °C
ECO TEMPERATURE 10 to 60°C 50 °C
Settings / DHW / standard setting Setting range Standard System value
DHW HYSTERESIS 1 to 10K 5K
DHW LEARNING FUNCTION ON / OFF OFF
DHW CORRECTION 0 to 5 °C 3°C
COMBI CYLINDER ON / OFF OFF
PASTEURISATION ON / OFF OFF
