8.2 WPF 35 | 40 | 52 | 66
2
8
3
5
7
4
1
6
26�03�01�0797
INSTALLATION
DEVICE DESCRIPTION
1 Electrical terminals
2 Condenser
3 Fill & drain valve (heating)
4 Sight glass
5 Expansion valve
6 Fill & drain valve (brine)
7 Compressor
8 Evaporator
8.3 WPF 27 HT
2
8
3
5
7
4
1
6
26�03�01�0797
1 Electrical terminals
2 Condenser
3 Fill & drain valve (heating)
4 Sight glass
5 Expansion valve
6 Fill & drain valve (brine)
7 Compressor
8 Evaporator
