Attaching Machine to Shoulder Strap
N Attach the carabiner (1) to the
carrying ring (2) on the shaft.
Balanced Position
N The cutting attachment should just
touch the ground.
The correct balanced position is
obtained as follows:
Balancing the Machine
N Loosen the screw (3).
N Move the carrying ring (2) up or
down the shaft – tighten the screw
moderately – let the machine go and
wait until it comes to a rest – then
check the balanced position.
When the correct balanced position has
been reached:
N Tighten down the screw on the
carrying ring firmly.
Disconnecting Machine from Shoulder
Strap
N Press down the bar on the
carabiner (1) and pull the carrying
ring (2) out of the carabiner.
Throwing Off the Machine
WARNING
The machine must be quickly thrown off
in the event of imminent danger. To
throw off the machine, use the
procedure described under
"Disconnecting Machine from Shoulder
Strap". Practice removing and putting
down the machine as you would in an
emergency. To avoid damage, do not
throw the machine to the ground when
practicing.
Balancing the Machine
1
2
1
2
0000-GXX 1056-A0
0000-GXX-0573-A0
3
2
0000-GXX 1057-A0
2
1
2
0000-GXX 1058-A0
1
