Stihl MS 261 C User Manual

17MS 261, MS 261 C
Condition Cause Remedy
Engine speed drops quickly under
load – low power
Air filter dirty Clean air filter or replace if
necessary
Throttle shutter not opened fully Check throttle cable and rod
Tank vent faulty Replace tank vent
Fuel pickup body dirty Install new pickup body
Fuel strainer dirty Clean fuel strainer in carburetor,
replace if necessary
Leak on fuel hose from tank to
carburetor
Seal connections or install new fuel
hose
Setting of high speed screw H too
rich
Check basic carburetor setting,
correct if necessary
Main jet bores or ports blocked Clean the carburetor
Pump diaphragm damaged or
fatigued
Fit new pump diaphragm
Ignition timing wrong, flywheel out
of adjustment
– key in flywheel has sheared off
Install new flywheel
Engine running extremely rich, has
no power and a very low maximum
speed
Choke shutter does not open Check carburetor and choke shaft,
service or replace if necessary

Stihl MS 261 C Specifications

General

Displacement	50.2 cm³
Powerhead Weight	4.9 kg
Sound pressure level	103 dB(A)
Sound power level	116 dB(A)
Vibration level (left/right)	3.5/3.5 m/s²
Bar Length	40 cm (16 in.)
Fuel Capacity	500 cc
Oil Capacity	270 ml (9.1 oz.)
Chain pitch	3/8"
Engine Power	3.0 kW
