Stihl MS 261 C User Manual

86 MS 261, MS 261 C
: Push the handlebar (1) into its
seat (arrow) and hold it there.
: Insert and tighten down the
screws (1) firmly.
5902RA298 TG
1
5902RA351 TG
1
1
– Push the tank housing (2)
upwards and hold it there.
: Insert and tighten down the
screw (1) firmly.
– Reassemble all other parts in the
reverse sequence.
1
5902RA257 TG
2

Stihl MS 261 C Specifications

General

Displacement	50.2 cm³
Powerhead Weight	4.9 kg
Sound pressure level	103 dB(A)
Sound power level	116 dB(A)
Vibration level (left/right)	3.5/3.5 m/s²
Bar Length	40 cm (16 in.)
Fuel Capacity	500 cc
Oil Capacity	270 ml (9.1 oz.)
Chain pitch	3/8"
Engine Power	3.0 kW
