Stihl MS 462

0458-786-0121-A
42
English 19 Specifications
19.1 STIHL MS 462 Chainsaw
– Displacement: 72.2 cc
– Engine power to ISO 7293: 4.4 kW (6 bhp)
– Idle speed to ISO 11681: 3,000 ± 50 rpm
– Approved spark plug: NGK CMR6H from STIHL
– Electrode gap: 0.5 mm
– Dry weight without guide bar and chain 6.0 kg
– Max. fuel tank capacity: 720 cc (0.72 l)
– Max. oil tank capacity: 340 cc (0.34 l)
19.2 Chain Sprockets and Chain Speeds
The following chain sprockets may be used:
– 7-tooth for 3/8"
– Maximum chain speed according to ISO 11681:
28.9 m/s
– Chain speed at maximum power: 21.7 m/s
19.3 Minimum Groove Depth of Guide Bars
The minimum groove depth depends on the pitch of the
guide bar.
–3/8" 6mm
19.4 Noise and Vibration Data
– Sound pressure level L
p
measured according to
ISO 22868: 108 dB(A) K-value for noise pressure level is
2 dB(A).
– Sound power level L
w
measured according to ISO 22868:
119 dB(A) K-value for sound power level is 2 dB(A).
– Vibration level ahv, eq measured according to ISO 22867
– Handlebar: 4.8 m/s² K-value for vibration level is 2 m/s².
– Control handle: 3.6 m/s² K-value for vibration level is
2m/s².
For further details on compliance with Vibration Directive
2002/44/EC visit www.stihl.com/vib
19.5 REACH
REACH is an EC regulation and stands for the Registration,
Evaluation, Authorisation and Restriction of Chemical
substances.
For information on compliance with the REACH regulation
see www.stihl.com/reach.
19.6 Exhaust Emissions
The CO
2
value measured in the EU type approval procedure
is specified at www.stihl.com/co2.
The measured CO
2
value was determined on a
representative engine in accordance with a standardized
test procedure under laboratory conditions and does not
represent either an explicit or implied guarantee of the
performance of a specific engine.
The applicable exhaust emission requirements are fulfilled
by the intended usage and maintenance described in this
instruction manual. The type approval expires if the engine
is modified in any way.
19 Specifications
