Stihl MSA 60.0 C User Manual

8 Engaging and Disengaging
the Chain Brake
8.1 Engaging the Chain Brake
The saw is equipped with a chain brake.
The chain brake is activated by the inertia of the
front hand guard if the kickback force is high
enough or can be engaged by the operator.
0000-GXX-1210-A0
► Push the hand guard away from the handlebar
with your left hand.
The hand guard engages with an audible click.
The chain brake is engaged.
8.2 Disengaging the Chain Brake
0000-GXX-1211-A0
► Pull the hand guard toward the handlebar with
your left hand.
The hand guard engages with an audible click.
The chain brake is disengaged.
9 Removing and Fitting the
Battery
9.1 Fitting the Battery
► Engage the chain brake.
0000-GXX-1208-A0
1
2
3
► Insert the battery (1) in the battery compart‐
ment (2) and press it home until you hear a
click.
Arrows (3) on battery (1) are still visible and
battery (1) is held securely in battery compart‐
ment (2). There is no electrical contact
between the saw and battery (1).
► Push the battery (1) into the battery compart‐
ment (2) as far as stop.
The battery (1) engages with a second click
and is flush with the saw’s housing.
9.2 Removing the battery
► Stand the saw on a level surface.
0000-GXX-1209-A0
1
2
► Press the locking lever (1).
The battery (2) is unlocked and can be
removed.
10 Switching the Saw On/Off
10.1 Turning on the Chainsaw
► Hold the chain saw by the control handle with
your right hand, wrapping your thumb around
the control handle.
► Disengage the chain brake.
► Hold the chain saw by the handlebar with your
left hand, wrapping your thumb around the
handlebar.
1
32
0000087078_002
► Press and hold the lockout button (2) with your
thumb.
► Press the trigger (3) with your index finger and
keep it depressed.
The chain saw accelerates and the chain
starts moving. Release the locking button (2).
8 Engaging and Disengaging the Chain Brake English
0458-022-8301-A 17
