Fault LEDs on the
battery
Cause Remedy
Charging does
not start when
the battery is
inserted into the
charger.
1 LED emits
red light.
The battery is too
warm or too cold.
► Leave battery inserted in charger.
Charging starts automatically as soon as
the permitted temperature range is
reached.
19.2 Troubleshooting the Charger
Fault LED on
Charger
Cause Remedy
Battery not being
charged.
The LED
flashes red.
No electrical contact
between charger and
battery.
► Remove the battery.
► Clean contacts on charger.
► Insert battery.
There is a malfunction
in the charger.
► Do not use the charger and contact your
STIHL dealer for assistance.
20 Specifications
20.1 STIHL MSA 60.0 C,
MSA 70.0 C Chainsaws
MSA 60.0 C
–
Approved battery: STIHL AK
–
Weight without battery, guide bar and saw
chain: 2.5 kg
–
Max. oil tank capacity: 110 cm³ (0.11 l)
MSA 70.0 C
–
Approved battery: STIHL AK
–
Weight without battery, guide bar and saw
chain: 2.5 kg
–
Max. oil tank capacity: 110 cc (0.11 l)
For runtime, see www.stihl.com/battery-life.
20.2 Chain Sprockets and Chain
Speeds
MSA 60.0 C
The following chain sprockets may be used:
–
6-tooth for 1/4" P
–
Maximum chain speed: 14.0 m/s
MSA 70.0 C
The following chain sprockets may be used:
–
6-tooth for 1/4" P
–
Maximum chain speed: 14.0 m/s
20.3 Minimum groove depth of guide
bars
The mininum groove depth depends on the pitch
of the guide bar.
–
1/4" P 4 mm
20.4 STIHL AK Battery
–
Battery technology: lithium-ion
–
Voltage: 36 V
–
Capacity in Ah: see rating label
–
Energy content in Wh: see rating label
–
Weight in kg: See rating label
20.5 STIHL AL 101 Charger
–
Rated voltage: See rating plate
–
Frequency: see rating plate
–
Rated power: see rating plate
–
Charging current: See rating plate
For charging times, see www.stihl.com/charging-
times.
20.6 Extension Cords
If an extension cord is used, the cross sectional
area of its conductors must meet the following
minimum requirements – depending on the line
voltage and length of the extension cord:
If rated voltage on the rating label is 220V to
240V:
–
Cord length up to 20 m: AWG 15 / 1.5 mm²
–
Cord length 20 m up to 50 m: AWG 13 /
2.5 mm²
If rated voltage on the rating label is 100V to
127V:
–
Cord length up to 10 m: AWG 14 / 2.0 mm²
–
Cord length 10 m up to 30 m: AWG 12 /
3.5 mm²
20 Specifications English
0458-022-8301-A 27
