4 Use and Operation
Use of the truck
Truck steering direction
D
F
BB
OM2314
CE
AA
H
G
Use the tiller to steer during travel.
• When the tiller is turned anti-clockwise (G)
while travelling towards (A), the truck steers
towards (C)
• When the tiller is turned anti-clockwise (G)
while travelling towards (B), the truck steers
towards (D)
• When the tiller is turned clockwise (H) while
travelling towards (A), the truck steers
towards (E)
• When the tiller is turned clockwise (H) while
travelling towards (B), the truck steers
towards (F)
