4 Use and Operation
Battery
2324
A
C
B
Instructions for recharging (specific
to 1400-kg version with "FULL LEAD"
batteries)
Follow the instructions below:
• Lift the battery compartment cover (A)
• Take the plug (B) of the on-b
oard battery
charger and connect it to th
esocket.
• The yellow LED (C) lights up and begins to
flash.
• When charging is completed, the LED (C)
turns green.
• Replace the plug in its hous
ing.
• Close the battery compartment cover.
WARNING
If there is an alarm or a problem, the LED (C) turns
red.
Contact the technical service department authori-
sed by the manufacturer.
1
2256
2
Battery electrolyte level indicator
LED (optional)
There are two versions of the LED:
• 1) Located on
the battery
• 2) Located next to the battery plug.
The LED indicates whether it is necessary to
top up the distilled water in the battery.
Operation:
• If the LED (1
) or (2) is green, there is a
sufficient l
evel of electrolyte in the battery.
The battery
must not be topped up with
distilled w
ater.
• If the LED (1) or (2) is red, there is an
insufficient level of electrolyte in the battery.
The battery must be topped up with distilled
water.
66
45588043482 EN - 04/2016
