Use and Operation 4
Battery
1
1843
2
3
4
Instructions for recharging - (excluding
1400 kg version)
Follow the instructions below:
• Lift the battery cover (1)
• Take the plug (2) of the on-boa
rd battery
charger and connect it to the
socket.
• The green LED (3) begins to flash
• When charging is completed, the green
LED (3) remains lit.
• Replace the plug in its hous
ing.
• Close the battery compartment cover.
WARNING
The red LED (4) indicates that the battery has been
left to charge for too long.
Do not leave the battery to charge for longer than
24 hours.
A
2251
C
B
Instructions for recharging (specific to
1400-kg version with GEL batteries)
Follow the instructions below:
• Lift the battery compartment cover (A)
• Take the plug (B) of the on-board battery
charger and connect it to the socket.
• The yellow LED (C) lights up and begins to
flash.
• When charging is completed, the LED (C)
becomes green and flashes slowly.
• Replace the plug in its housing.
• Close the battery compartment cover.
WARNING
If there is an alarm or a problem, the LED (C) turns
red.
Contact the technical service department authori-
sed by the manufacturer.
45
588043482 EN - 04/2016 65
