StoneL Prism PI - 6 Model;Type Code

StoneL publication 105431revC
7 PI 70 en Prism PI | 27
6 Model/Type code
Model selector
SERIES
PI Nonincendive or intrinsically safe
FUNCTIONS
Sensors modules Valve communication Terminals (VCTs)
33S (2) SST NO switching sensors 92S DeviceNet™
45S (2) NAMUR sensor (EN 60947-5-6; I.S.) 92W DeviceNet™ with Wireless Link
96S AS-Interface
96W AS-Interface with Wireless Link
97S AS-Interface with extended addressing
97W AS-Interface with extended addressing and Wireless Link
Expeditor, standard stroke Expeditor, long stroke
80S (1) 4-20mA AO for position control
81S
(1) 4-20mA AO for position control with (1) 4-20mA AI and (2) 24V DI for position
feedback
80W (1) 4-20mA AO for position control with Wireless Link
81W
(1) 4-20mA AO for position control with (1) 4-20mA AI and (2) 24V DI for position
feedback with Wireless Link
PNEUMATIC VALVE / TEMPERATURE
-20° C to 60° C / 0.1 Cv -10° C to 50° C / 0.2 Cv
11S No pneumatic valve 1KS Three-way 24 VDC
1NS Three-way voltage / power depends on function 1MS Three-way 120 VAC
2KS Dual three-way 24 VDC
ENCLOSURE
A North American (NEC/CEC)
V International (IEC)
L Other
CONDUIT/CONNECTORS
Standard Mini-connectors Micro-connectors (M12)
01 (1) ½” NPT 10 (1) 4-pin 13 (1) 4-pin
02 (2) ½” NPT 11 (1) 5-pin 14 (2) 4-pin
04 (1) M20 19 (1) 6-pin 15 (1) 5-pin
05 (2) M20 17 (1) 6-pin
08 (1) cable glands
09 (2) cable glands
VISUAL INDICATOR
R Green open 0 No indication
VALVE SIZE
S Standard stroke - ¼” to 2” (3.2 mm to 28.5 mm; ⁄” to 1 ⁄” stroke)
L Long stroke - ¼” to 6” (3.2 mm to 66.8 mm; ⁄” to 2 ⁄” stroke)
BRANDING
A StoneL
M Neles
Model number example
PI 33S 1KS A 01 R S A OPTIONAL
MODEL NUMBER PARTNERSHIP ID
Mounting hardware required and sold separately. Some models may include 5-digit identication sux.
