Stonex S580 GNSS Receiver – User Manual 5
The receiver interface description will be shown in the following table.
Num.
Item
Description
1
Connection led indicator
Blue flash when Bluetooth/Wi-Fi connected
2
Data link led indicator
Green flash when differential data transmitting
3
Satellite led indicator
Green flash according to number of satellites tracked
4
Battery led indicator
• Green always on when normally operating
• Red flash with warning beep when power is less than 10%
• Red always on in charging
• Green on when charging finished
5
Power button
Button to turn on/off the receiver
6
USB type-C port
Type C port supports USB 2.0, not OTG
