Stonex S700A GNSS Receiver User Manual 9
2.2.1 Working mode
You can select different work mode to configure, static, rover and base. In
different mode, there are different configuration you can make.
Static Mode
It’s possible input the point name, antenna height, PDOP threshold. And the
antenna measurement and collect interval. These are all the parameters can
be used in static collection.
At last, there are two record options. If you activate auto record, it will collect
data automatic when you power on the receiver.
Rover Mode
In rover mode, you can select different datalink. Different datalink also has
different options can be edited. The datalink includes Network, External and
Bluetooth.
If you select Network, then besides select aRTK timeout and record raw data,
the most important is you can input CORS information, such as IP, account.
If you select External, then it can connect to external radio. There is a very
important thing, the external serial port band rate, this should be same with
external radio.
Then the last it’s Bluetooth, after selecting the datalink as Bluetooth, there
are little option that you can configure.
Base Mode
Base mode also contains different datalink, most of the parameters are same.
The only difference is the base mode has some more options can be edited.
For example you can set the base data type, start base and base position and
so on.
If you select Network, then besides set the data type, site ID, base position
and record raw data, the most important is you can input APN account, APN
user and password, connect mode, caster address and port.
