Stormshield SN900 - Page 27

Page 27 /59 snengde_installation-product-SN-range v1.2 - Copyright Netasq 2015
PRESENTATION AND INSTALLATION GUIDE – SN RANGE
PRESENTATION OF "SN" MODELS
SN200, SN300, SN500, SN700, SN900 and SN910 models
Name
Color
Status
Indication
Left LED
ACT/LINK
Green
On
Link established between the Ethernet port and the connected
appliance.
Off
Ethernet port switched off or link not established with the
connected appliance.
Blinking
The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Right LED
SPEED
Yellow
On
Media speed negotiated at 1 Gbps.
Green
On
Media speed negotiated at 100 Mbps.
Off
Media speed negotiated at 10 Mbps.
SN2000 and SN3000 models
Front and rear panel
Name
Color
Status
Indication
Left LED
ACT/LINK
Green
On
Link established between the Ethernet port and the connected
appliance.
Off
Ethernet port switched off or link not established with the
connected appliance.
Blinking
The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Right LED
SPEED
Yellow
On
Media speed negotiated at 1 Gbps.
Green
On
Media speed negotiated at 100 Mbps.
Off
Media speed negotiated at 10 Mbps.
