PRESENTATION AND INSTALLATION GUIDE – SN RANGE
PRESENTATION OF "SN" MODELS
SN6000 model
Front panel
Name
Color
Status
Indication
Left LED
ACT/LINK
Green
On
Link established between the Ethernet port and the connected
appliance.
Off
Ethernet port switched off or link not established with the
connected appliance.
Blinking
The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Right LED
SPEED
Yellow
On
Media speed negotiated at 1 Gbps.
Green
On
Media speed negotiated at 100 Mbps.
Off
Media speed negotiated at 10 Mbps.
Rear panel
IPMI
Name
Color
Status
Indication
Left LED
LINK
Green
On
Link established between the Ethernet port and the connected
appliance (100 Mbps).
Off
Ethernet port switched off or link not established with the
connected appliance.
Right LED
ACTIVITY
Yellow
Blinking
The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Off
Ethernet port switched off or link not established with the
connected appliance.
MGMT1/2
Name
Color
Status
Indication
Right LED
ACT/LINK
Green
On
Link established between the Ethernet port and the connected
appliance.
Off
Ethernet port switched off or link not established with the
connected appliance.
Blinking
The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Left LED
SPEED
Yellow
On
Media speed negotiated at 1 Gbps.
Green
On
Media speed negotiated at 100 Mbps.
Off
Media speed negotiated at 10 Mbps.
