- Perfect Protective Packaging 8
6.1 Keypad Functions
7. Setting Up the Device for Use
7.1 Assembly of the Film Roll Holder
Remove the AIRmove
2
machine and the blue film roll shaft from the box. Insert the metal part into hole on
the front side of the machine.
7.2 Film Roll Holder Positions for Smooth Film Flow
Airmove
2
films are available in three different options:
Film description
Air Pillow dimensions
Length
Void S, 25 µ
200 mm x 120 mm
350 m
Bubble M, 25 µ
400 mm x 160 mm (29b)
350 m
Cushion M, 25 µ
400 mm x 250 mm (16p)
350 m
Film description
US Air Pillow dimensions
Length
Void S, 1.0 mil
8” x 5”
1150’
Bubble M, 1.0 mil
16” x 9.76”
1150’
Cushion M, 1.0 mil
16”x 6”
1150’
Position
Name
Function
Start/Stop Button
Starts or stops the machine
Arrow up
Increases the value
Scrolls up
Arrow down
Decreases the value
Scrolls down
Enter Button
Confirms
Enter menu
Enter menu item
