Strapack iQ400 - StraPack iQ-400 Standard Specifications; StraPack iQ-400 Dimensional Outline Drawing

p. 4
Standard Specification
iQ-400
Outside North America
North America
Joint (Strap Weld)
Heat Seal / polypropylene
Dimensions
: Width
780mm
30-3/4 in.
: Height
777 mm
30-5/8 in.
: Table Height
752 mm
29-5/8 in.
: Depth
540 mm
22-1/2 in.
Machine Weight
Approx. 56 kg
Approx.123.5 lbs.
Tension
:Torque Mode
Up to 450 N ( 45.9kgf)
Up to 101 lbf
:Stroke Mode
150 mm
5-7/8 in.
Electric Power
Single Phase 200-240V 50/60Hz
Single Phase 110-120V50/60Hz
Full Load Current
12 A
14.5 A
SCCR (Sort-Circuit Current Rating)
0.5 kA
0.3 kA
Power Consumption
0.35 kW
Noise Emissions
57.2 dB (A) Measured according to EN-415-8 Annex A
Package
: Min. Size
W100×H30mm
W 3-1/8 x H 1-1/8 in.
: Max. Size
Unlimited
Unlimited
Strap
: Width
5, 6, 9, 12, 15.5 mm
5mm,1/4, 3/8, 1/2, 5/8 in.
: Thickness
0.4mm to 0.7mm
: Dispenser
Strap Coil
ID 200 x W200mm
Strap Coil
ID 200 or 230 x W200mm
(8x8in. or 9x8in.)
Dimensional Outline Drawing
