► Fit strap guide rear 9 mm (9) (secure cylinder screw with Loctite 222).
► Fit side cover (5) (secure cylinder screw with Loctite 222). Install strap guide rear 9 mm (8).
5.3.2 STB 73: Change from 13 mm to 16 mm (
1
/
2
″ to
5
/
8
″)
Required parts Order number
Strap guide rear 16 mm (
5
/
8
″) (8) 1832.041.018
► Remove battery from tool. Remove three cylinder screws Torx (6). Lift rocker lever towards the
handle, remove cylinder screw Torx (7) and strap guide rear 13 mm (
1
/
2
″) (8).
► Remove side cover (5).
► Remove counter-sunk screw Torx (2) and strap guide front 13 mm (1).
► Remove counter-sunk screw Torx (4) and strap guide front 13 mm (3).
► Remove cylinder screw Torx (10) and strap guide rear 13 mm (9).
► Fit side cover (5) (secure cylinder screw with Loctite 222). Install strap guide rear 16 mm (8).
STB 73: Change from 16 mm to 13 mm: (
5
/
8
″ to
1
/
2
″)
Required parts Order number
Strap guide front 13 mm (
1
/
2
″) (1) 1832.031.116
Strap guide front 13 mm (
1
/
2
″) (3) 1832.031.051
Strap guide rear 13 mm (
1
/
2
″) (9) 1832.042.043
Strap guide rear 13 mm (
1
/
2
″) (8) 1832.041.019
Counter-sunk screw Torx, M4x6 (2) (4) 1912.204.064
► Remove battery from tool. Remove three cylinder screws Torx (6). Lift rocker lever towards the
handle, remove cylinder screw Torx (7) and strap guide rear 16 mm (
5
/
8
″) (8).
► Remove side cover (5).
► Fit strap guide front 13 mm (1) (secure counter-sunk screw with Loctite 222).
► Fit strap guide front 13 mm (3) (secure counter-sunk screw with Loctite 222).
► Fit strap guide rear 13 mm (9) (secure cylinder screw with Loctite 222).
► Fit side cover (5) (secure cylinder screw with Loctite 222). Install strap guide rear 13 mm (8).
