Manual English V16/04 page 6
3 Description of the Hand-Bike for wheelchairs
The hand-bike is an additional equipment device, which can be attached to nearly every
modern wheelchair (except toilet seats, electric wheelchairs and similar vehicles).
It is recommended, to use wheelchairs with rigid frames but foldable wheelchairs are
also no problem with the hand bike it is possible to ride much longer distances with less
effort. The Hand-Bike can be attached without additional help in most cases. No parts
remain on the wheelchair after the Hand-Bike is removed. (except 2 small plastic
clamps if you like)
picture 1
4 Unpacking your Hand-Bike
For transport purposes, both handgrips are removed and the side tubes turned to the top.
After undoing the 2 bolts S1L and S1R (see picture 8) with the enclosed long Allen key,
both side tubes should be turned into their normal position (approx. 90 degrees in
relation to the steering tube) and be fixed. Screw both handgrips on the hand-cranks
with a 15mm spanner. (Attention! The left crank has a left-hand thread)
picture. 2
