Manual English V16/04 page 9
6 Separate your Hand-Bike from the wheelchair
Loosen the two levers H2L and H2R (picture 6); the front wheels of the wheelchair
come back to ground.
Then loosen the levers H1L and H1R and take the Hand-Bike off. Do not open the
levers too far.
Picture 6
Models with automatic click-in adjuster
Open the flaps on both sides with pushing them backwards.
Push the Hand-Bike with the handle forwards to release the automatic adjusters.
The bolts are pushed back automatically through the flaps and open (The flaps snap
to the outside).
Take the handle back and let the front wheels of the wheelchair come down slowly.
Attention: Never try to push the bolts back with power, the
flaps can be bent! Then loosen the levers H1L and H1R and take
the Hand-Bike off. Do not open the levers too far.
Abb.7
