5
2.0 YOUR RECEIVER
2.1 PIN code default: 0000
2.2 Front and side panel
Fig. 1
1. Remote control sensor:
Receives the signal from the remote control
2. LED display: Shows channel number in operation and time in Standby
3. Standby indicator: Shows power state of the receiver: Red LED - receiver is in
standby mode
4. Power button: Switch the receiver to Standby or On.
5. USB For connection of USB device for Multimedia use
2.3 Rear panel
Fig. 2
1. SAT IN To connect to the LNB of your satellite dish for reception of
satellite broadcast signal
2. Ethernet To connect to a network switch, router or modem
3. HDMI To connect to the HDMI input of your TV using a good quality
HDMI cable
4. TV SCART To connect to TV using a SCART cable
5. Audio L/R To connect to an analogue amplier for stereo audio
6. S/PDIF coaxial To connect to a digital or home cinema audio amplier
7. Power connector The receiver requires a wall adapter, mains voltage input
100~240V AC 50~60Hz 12V, 1.5A DC output. Please check the
local power conditions before connecting the receiver to the
mains supply.
2.4 Remote Control
Fig. 3
1. q Turns the receiver ON/Standby
2. ! To turn the sound on or o
3. 0-9 Channel number and numeric value input
4. TV/R Toggles between TV and radio mode
5. No function
6. FAV To access your favourite channels. Toggles between available
favourite groups
7. 9 To switch between the last viewed channels
8. AUDIO Displays the audio selection menu with selections for available
languages and audio modes
9. INFO Press once to display channel number/name and current/coming
information. Press twice to display detailed event information.
Press again to get back to viewing mode
10. EPG Viewing mode: Displays the EPG (Electronic Programme Guide)
