2.3 Rear Panel
Fig. 2
1. SAT IN To connect to the LNB of your satellite antenna for reception of satellite
broadcast signal.
2. IR To connect the separately available IR extender.
3. Ethernet To connect to to your home network via switch, router or modem.
4. HDMI To connect to the HDMI input of your TV set using a good quality HDMI cable.
5. S/PDIF (coax.) To connect to a digital amplifier or home theatre set.
6. TV SCART To optionally connect to your TV set using a SCART cable.
7. Power adapter To connect to the original included main power adapter (Input 100 ~240V
50~60Hz/ Output 12 V DC
).
2.4 Remote Control
Fig. 3
1. q Switches the receiver On/Standby
2. ! Mutes audio output of the receiver in every mode incl. videotext, the symbol
will not be shown within menu mode
3. 0~9 Channel selection or value input
4. TV/R Toggles between TV and RADIO mode
5. No function
6. FAV Opens the favourite list selection if previously configured
7. 9 Opens the recently watched channel list or switches between the two last
previously watched channels*
8. AUDIO Opens the list of audio languages
9. INFO Shows the actual channel information (2x event info, 3x technical info)
10. EPG Opens the EPG (Electronic Programme Guide) in TV mode
11. pq Menu Off: Change channel to next/previous. Menu On: Moves the cursor up/
down
12. tu Menu Off: Decreases/increases the volume level. Menu On: Change settings
and navigation in menu
13. OK Menu Off: Displays the current channel list. Menu On: Opens the highlighted
setting or for confirmation. In Videotext mode: Changing the transparency in
3 stages
14. MENU Opens the main menu; Within the menu switches to TV mode
15. One step back from each menu or to cancel actions
16. VOL+/VOL- Increases/decreases the volume in all modes (with TV picture in BG/Videotext)
17. P+/P Scroll page wise in all lists
18. LIST Opens the satellite list in TV mode. In EPG and Timer mode it opens the Timer
list
19. CH+/CH Channel up/down
20. OPT Opens the settings for TV format, aspect ratio and resolution
21. TEXT Opens the videotext if available
22. SUB Shows the list of DVB-subtitles if available
23. Gives direct access to mails from your broadcaster
24. 2 In Multimedia mode: To pause the playback of a file
25. RWD/FF In Multimedia mode: Fast rewind/Fast forward
26. 4 No function
27. u In Multimedia mode: Starts the playback of a selected file (Preview)
28. 7 8 In Multimedia mode: During playback to jump to the previous/next file
