150 l tank
Front view
A Recirculation pump
B Magnetic filter
C Control unit
D Filter tray
E Tank
F Water level gauge
150 l tank
Rear view
A Drain valve
4.2 Unpack the machine
Note
We recommend that you keep all original packaging and fittings for future use.
The equipment is delivered on a pallet and fastened with cable ties.The control unit is packed
separately.
1. Remove the transport case.
2. Remove the plastic wrapping.
3. Lift off the filter unit and pump cover and
remove the waste collection bin and the
water level gauge.
4.3 Check the packing list
Optional accessories may be included in the packing box.
The packing box contains the following items:
4 Installation
Cooli System 11
