4.6.2 Connection to the machine
• Connect the electrical power cable to the machine (C14
IEC 320 connector).
• Connect the cable to the electrical power supply.
Note
To keep water away from the connections (Protection Rating IP44), place the
cable box around the cable connections.
Note
To prevent the cables from trailing on the ground and being damaged, hang them
by the hooks in the cooling unit tank.
4.7 Filters
Filter bag
Insert the water outlet hose from the connected machine into
the hole that has the correct size.
