Big Wheel 4−Sided Control Base
60
Item Part No. Part Name Qty.
A 0021−166−000 Set Screw 2
B 0023−150−000 Hex Washer Hd. Screw 2
C 0023−288−000 Hex Washer Hd. Screw 4
D 0026−273−000 Clevis Pin 5
E 0026−330−000 Clevis Pin 1
F 0027−020−000 Rue Ring Cotter 6
G 0029−007−000 Dual Lock 5
H 0029−009−000 Dual Lock 5
J 0042−020−000 Collar 2
K 0081−330−000 Radial Bearing 1
L(page 51) Brake Rod Assembly 2
M(page 48) Base Assembly w/ Standard Brakes 1
N(page 52) Dual Sided Hydraulics 1
P(page 56) Cam Bracket Assembly 1
R 1040−006−231 Drive Arm 1
T 1040−015−007 Carriage Pivot Bushing 2
U(page 62) Side Control Big Wheel Carriage Ass’y 1
V 1040−025−026 Brake Rod Bushing 1
W 1210−201−251 Insert 3
