Stryker 1027 User Manual

Side Control Big Wheel Carriage Assembly
62
Item Part No. Part Name Qty.
A 0011−148−000 Washer 2
B 0011−525−000 Washer 2
C 0014−004−000 Washer 1
D 0026−341−000 Clevis Pin 1
E 0026−342−000 Groove Pin 3
F 0027−020−000 Rue Ring Cotter 1
G 0028−166−000 External Retaining Ring 1
H 0028−330−000 External Retaining Ring 1
J 0081−011−000 Needle Bearing 4
K 0081−175−000 Thrust Bearing 2
L 0753−003−099 Butterfly “V” Pedal 2
M 0753−003−219 Side Control Brake Rod 1
N 1040−015−006 Carriage Return Spring 1
P 1040−015−038 Washer 1
R 1040−015−053 Carriage Spring Retainer 1
T 1040−020−122 Cam Follower Pivot Pin 1
U 1040−020−128 Lift Cam Roller 1
V 1040−020−129 Carriage Roller Guide 1
W(page 63) Side Control Linkage Ass’y 1
X 1040−025−014 Side Control Wheel Spacer 2
Y 1040−025−017 Side Control Pedal Spacer 2
AA 1040−025−030 Cover w/Counterweight 2
AB 1040−025−110 4−Sided Carriage 1
AC 1210−201−335 Red Brake Label 2
AD 1210−201−336 Green Steer Label 2
AE 1210−301−619 Wheel Assembly 2
Return to Table of Contents
