Base Labeling Assembly − Big Wheel Base
64
Specification Label
HEAD END
FOOT END
Assembly part number 1040−015−400 (reference only)
Department Label
see page 67
Item Part No. Part Name Qty.
A 1040−010−134 Bellows 2
B 1040−015−404 Base Hood 1
C 0946−201−060 Stryker Logo Label 4
