Litter Assembly
72
Item Part No. Part Name Qty. Item Part No. Part Name Qty.
A 0003−035−000 Hex Hd. Cap Screw 2 AX (page 73) Siderail Ass’y, Left 1
B 0003−047−000 Hex Hd. Cap Screw 28 AY 1010−026−069 Lock Support 2
C 0003−050−000 Hex Hd. Cap Screw 2 AZ 1010−026−081 Lock Housing, Left 1
D 0003−054−000 Hex Hd. Cap Screw 4 BA 1010−026−080 Lock Housing, Right 1
E 0003−074−000 Hex Hd. Cap Screw 2 BC 1010−032−092 Foley Bag Rack 1
F 0003−078−000 Hex Hd. Cap Screw 8 BD 1020−001−040 Foot Board Support 1
G 0004−021−000 Soc. Hd. Cap Screw 4 BE 1020−001−042 Roller Support, Left 2
H 0004−515−000 But. Hd. Cap Screw 14 BF 1020−001−043 Roller Support, Right 2
J 0004−161−000 But. Hd. Cap Screw 4 BG 1020−001−053 Centering Label 1
K 0008−024−000 Soc. Hd. Cap Screw 4 BH 1020−001−059 Trend Roller Bar 2
M 0014−003−000 Washer 4 BJ 1020−001−061 Litter Frame Ass’y 1
N 0014−021−000 Washer 4 BK 1020−022−023 Guide Tube Assembly 2
P 0016−028−000 Hex Nut 44 BM 1020−022−026 Adjustment Bracket 2
R 0016−035−000 Nylock Hex Nut 2 BN 1020−022−028 Label, Release 1
S 0021−104−000 Set Screw 2 BP (page 74) Foot End Litter Support 1
T 0023−288−000 Hex Hd. Washer Screw 2 BR (page 75) Head End Litter Support 1
W 0025−038−000 Rivet 20 BS 1020−026−021 Bumper Channel 2
Y 0025−099−000 Rivet 32 BZ 1020−032−019 Pivot Bolt 2
Z 0028−023−000 External Retaining Ring 2 CA 1020−032−025 Foot Section Weldment 1
AA 0037−049−000 Rectangular Hole Plug 8 CB 1020−032−031 Litter Riser, Right 1
AB 0037−059−000 Hole Plug 1 CC 1020−032−032 Litter Riser, Left 1
AC 0037−063−000 Hole Plug 2 CD 1020−091−052 Centering Label 2
AD 0037−074−000 Hole Plug 2 CE 1020−032−026 Foot Section Skin 1
AG 0721−026−066 Pivot Screw 14 CF 1210−800−008 Patent Label 1
AH 0721−026−069 Upright Sleeve 10 CG 0038−220−000 Compression Spring 2
AJ 0721−026−074 Lock Handle 2 CH 0001−096−000 Flat Cs’k. Hd. Mach. Scr. 4
AK 0721−032−049 Roller Bumper 4 CJ 1010−001−013 Foot End Cover, Right 1
AM 0721−040−026 Foot Board Receptacle 2 CK 1010−001−014 Foot End Cover, Left 1
AT 1010−001−017 Roller Plate 4 CL 1010−026−103 Spring Retainer 2
AW (page 73) Siderail Ass’y, Right 1
