WIRE HARNESS ROUTING
ROUTE ALL HARNESSES AS SHOWN.
LOOP RAIL ARM HARNESS AS SHOWN,
ORIENT P-CLIP HORIZONTALLY.
CONNECT TO PCBA.
ROUTE HARNESSES UNDER
PLATE TABS AS SHOWN.
48
48
CABLE T
IE WIRES NEATLY
TO BACKPLATE
CABLE T
IE WIRES NEATLY
TO BACKPLATE
13
33
2X
15
EN 104 5900-009-002 Rev A.0
