IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
1 5900240045 Deck weldment, knee section 1
2 5900200072 Deck pan assembly, knee section,
patient left
1
3 5900200073 Deck pan assembly, knee deck, patient
right
1
4 5900500041 Pinion shaft, knee deck 1
5 5900560003 Pinion gear, expandable deck 2
6 5900600007 Bushing, pinion shaft cover 1
7 5900620008 Cover, knee deck 1
8 5900330007 Bushing, flg 0.313x0.375x0.125lg (flg
0.500x0.032)
1
9 5900330003 Bushing, flg 0.375x0.500x0.313lg (flg
0.625x0.062)
4
10 5900600035 Mattress keeper, short 2
11 0025-120-000 Rivet, 1/4 x 0.600" lg blind alum 4
12 5900340090 Screw, sems pan ph #10-32unf x 3/4lg
int wash zinc
4
13 5900200159 Handle assembly, deck expansion 2
14 5900370022 Grommet, push-in locking 5/8" hole 4
15 5900340017 Screw, pan ph #8-unc x 0.3125 2
16 5900340114 Screw, plastite pan head ph #10-14 x 1/
2" lg ZnPL
4
17 5900340081 Screw, flat Torx head 5/16-18 x 3/4 tri
lobe zinc
4
5900-009-002 Rev A.0 71 EN
