EErrrroorr ccooddee CCaauussee
TTrroouubblleesshhoooottiinngg
0.27 AVB board is not responding
(AVB_missing)
1. Check cables
2. Check junction boards
0.29 Real Time Clock is not responding
(RTC chip fail)
1. Reboot product
2. Replace MCU, if 0.02 is present, also issue with
PMB charger chip
3. Replace PMB
0.3 CPR handle switch stuck
(StuckCPRhandle)
1. Check CPR handle
2. Check pull cable
3. Check head actuator
1.05 24V is out of range
(24V)
1. Power cable issue
2. PMB ciruit error, replace PMB
1.08 Battery not connected to the system or completely
depleted
(batteryMissing)
1. Check cables
2. Replace battery
1.09 Damaged battery
(batteryShort)
1. Replace batteries
1.1 Unable to communicate with accelerometer
(Accelerometer error)
1. Reboot product
2. Replace MCU, if 0.02 is present, also issue with
PMB charger chip
3. Replace PMB
1.11 HILO foot configuration error
(HiloFoot config)
1. WD switch position
2. Reboot product
1.12 HILO foot drive circuit error
(HiloFoot Drive ckt)
1. Check 24V cable to ACB
2. Disconnect actuator from ACB
3. Replace ACB
1.13 HILO head configuration error
(HiLo Head config)
1. WD switch position
2. Reboot product
3. Check HILO head potentiometer cable (30159)
4. Check HILO head counts in actuator
maintenance menu
5. Check HILO head counts in angle maintenance
menu
• Check if counts are between 1024-1033 or
not moving
6. Check HILO foot potentiometer cable (30124)
7. Recalibrate angles
EN 14 5900-009-002 Rev A.0
