1
20
2X
16
2X
22
2X
8
2X
21
2X
4
9
19
2X
23
2X
14
15
56
24
13
2
17
8X
7
18
6X
25
6X
11
18
3X
25
3X
3
10
2X
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
1 5900650002 Panel, footboard FSC 60° 1
2 5900600014 FSC bezel, front plate 1
3 5900600015 FSC bezel, back cover 1
4 5900600016 Integrated hanger bracket, footboard 1
5 5900600081 Insert, watchdog light blocker 1
6 5900400032 PCBA, FSC iBed light 1
7 5900470017 Keypad, FSC 4.3" LCD standard 1
8 5900540254P Post, footboard plated 2
9 5900690017 Overlay, blank Ø1.00 round white 4
10 5900690024 Overlay, hanger brkt swl / refer to
manual
2
11 5900690060 Overlay, front FSC iBed light 1
12 5900690080 Label, lock/unlock footboard 1
13 5900430138 HRNS, watchdog light 1
14 5900430119 HRNS, FSC blow mold 1
15 5900340117 Screw, machine pan PH #4-40 x 0.50
LG zinc
1
16 5900370080 Plug, tube finishing Ø1.0 OD x Ø0.74-
Ø0.83 ID blk
2
17 5900340071 Screw, sems pan PH #6-32x3/8LG int
wash zinc PL
8
18 5900340115 Screw, plastite pan head PH #10-14 x 7/
8" LG ZnPL
9
19 5900340087 Screw, sems pan head PH #8-32 x 3/4"
LG zinc PL
2
EN 118 5900-009-002 Rev A.0
