LLoocckk aasssseemmbbllyy,, hheeaadd ddeecckk ppoossiittiioonn
5900200051 Rev A (Reference only)
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
1 5900600048 Housing, deck lock/position sensor 1
2 5900600049 Cover, deck lock/sensor housing 1
3 5900500033 Pin, deck lock 1
4 5900370017 Spring, compression deck lock 1
5 5900520100 Plate, deck lock cable mount 1
6 5900430030 HRNS, deck lock/position snsr head
deck
1
7 5900600053 Arm, deck lock sensor plunger 1
8 5900340009 Screw, pan ph #6-unc x 0.375 tri lobe 2
9 5900340018 Screw, #4-20 tri-lobular 3/8lg 4
10 5900370018 Binding barrel, 10-24 x 3/4lg zinc plated 1
11 0004-665-000 Screw, bhcs #10-unc x 0.313 w/patch 1
12 590040004101 PCBA, iom deck pos mon head 1
13 5900370011 Cable, deck extend push/pull 2
5900-009-002 Rev A.0 67 EN
