Stryker MV3 5900 Maintenance Manual

DDeecckk ppaann aasssseemmbbllyy,, ffoooott ddeecckk,, ppaattiieenntt lleefftt
5900200074 Rev A (Reference only)
2
3
2X
4
4X
1
2X
6
4X
5
4X
6
4X
8
2X
7
2X
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
1 5900560011 Rack, expandable deck 2
2 5900240050 Pan weldment, foot deck, patient left 1
3 5900600006 Bearing, expandable deck guide 2
4 5900600034 Roller, expandable deck 4
5 5900500028 Pin, expandable deck roller 4
6 0025-079-000 Rivet, 3/16 domed sst 8
7 5900370022 Grommet, push-in locking 5/8” hole 2
8 5900310020 Nutsert, #10-UNF thick sheet hex body-
zinc
2
EN 82 5900-009-002 Rev A.0
