Stryker MV3 5900 Maintenance Manual

RRaaiill aasssseemmbbllyy,, hheeaadd
5900200130 Rev C (right) (Reference only)
5900200131 Rev C (left) (Reference only)
2
3
1
20
2X
31
2X
38
4X
22
2
X
53
49
2X
52
2X
50
51
CA
M LOBE ORIENTATION
(I
DENTIFICATION MARKS FACE OUTWARD)
FLEX CABLE TO BE INSTALLED WITH
RED LABEL INDICATOR FLUSH WITH
END OF CASTING. ( 1/4")
ROUTE ARM CABLES UNDER
POSTS & CONNECT TO PCBA
CASTING CUT-AWAY
FOR CLARITY
5900-009-002 Rev A.0 93 EN
