Stryker MV3 5900 Maintenance Manual

19
2X
28
2X
18
2X
10
16
29
17
7
APPLY NS-18191-G
GREASE TO LENGTH
OF RACK
APPLY NS-18191-G
GREASE TO LENGTH
OF RACK
TIGHTEN RACK MESH SET SCREW TO ENSURE GEAR
MESH IS TIGHT. FUNCTIONALLY CYCLE TEST TO ENSURE
CORRECT SETTING FOR GRAVITY FALL AND "HITCH"
ADJUST BOTH LEVER SET SCREWS AT THE SAME TIME.
RACK MESH
ADJUSTING
SET SCREW
AFTER MESH IS TIGHT, TORQUE ALL GEAR
SCREWS TO 45IN/LB (TWICE AROUND)
12
9
8
36
27
2X
26
2X
35
2X
11
26
2X
37
22
16X
8.00 0.5
0.25
PLACE TAPE APPROXIMATELY AS SHOWN ON BACKPLATE
1137
5900-009-002 Rev A.0 95 EN
