A Series Active Monitor Speakers
Date printed: 29.02.00 Welcome! E1/3
1.2 Safety and Connections
1.2.1 Utilization for the Purpose Intended
The Studer A series active speakers are designed for professional use. It is
presumed that the units are operated only by trained personnel; servicing
must be performed by qualified experts.
The electrical connections may be connected only to the appropriate volt-
ages and signals specified in this manual. Please consult the Safety and
EMC sections at the very beginning of this manual.
1.2.2 Unpacking and Inspection
Your new unit is shipped in a special packing which protects it against me-
chanical shock during transit. Care should be exercised when unpacking so
that its surfaces do not get marred.
Verify that the content of the packing agrees with the items listed on the
enclosed shipping list. Check the condition of the equipment for signs of
shipping damage. If there should be any complaints please immediately no-
tify the forwarding agent and your nearest Studer distributor.
Please retain the packing material because it offers the best protection in
case your unit ever needs to be transported.
1.2.3 Installation
Before any connection: Check the line voltage selector setting before connecting the unit to the
mains. The voltage selector is located inside the fuse holder next to the
power inlet. The unit can be operated on mains voltages of 115 or 230 V
AC
,
50 to 60 Hz. Also check for correct value of the primary fuse:
A1
230 V: T 1.6 A L 250 V (5 × 20 mm)
115 V: T 3.15 A L 250 V (5 × 20 mm)
USA and Canada: 115 V: 3.2 A slow blow UL/CSA (5 × 20 mm)
A3
230 V: T 0.8 A L 250 V (5 × 20 mm)
115 V: T 1.6 A L 250 V (5 × 20 mm)
USA and Canada: 115 V: 1.6 A slow blow UL/CSA (5 × 20 mm)
A5
230 V: T 0.5 A L 250 V (5 × 20 mm)
115 V: T 1.0 A L 250 V (5 × 20 mm)
USA and Canada: 115 V: 1.0 A slow blow UL/CSA (5 × 20 mm)
Mains cable: Depending on your country, the A Series Active Monitor Speakers come
with an IEC mains cable or a female IEC 320/C13 mains cable socket. This
socket has to be connected to an appropriate mains cable by a trained tech-
nician with respect to your local regulations. Refer to the “Installation” sec-
tion at the beginning of this manual.
