A Series Active Monitor Speakers
E4/14 Service Date printed: 29.02.00
4.4.1 A3: Settings on the PCB
4.4.1.1 A3: Required Test Tools
T1 Variable mains transformer (variac)
A1 True-RMS AC ammeter
V1 True-RMS AC voltmeter
V2…V5 Digital DC voltmeter
G1 Sine-wave generator with balanced output (min. 20 Hz…20 kHz, < 0.02%
THD)
M1, Mw, Mt Voltmeter, THD meter, phase meter
RLw, RLt Dummy load resistors, 10 , approx. 10 W
Rdt Fixed resistor, 22 kΩ, for overheat protection check
Note: G1, M1, Mw, Mt can be replaced by a universal audio test system (Audio-
Precision System One or equivalent)
4.4.1.2 A3: Initial Settings
Note: Replacement backpanel assemblies or amplifier units come factory-pre-
adjusted. Adjustment of the quiescent current is therefore not necessary
after replacement, checking is recommended nevertheless.
Unplug the speaker cables from the PCB, do not connect any load to the
amplifier outputs. Make sure that none of the cable ends contacts the PCB;
Set the level potentiometer to CAL position (fully counterclockwise);
Set the roll-off potentiometer to CAL position (fully counterclockwise);
Set trimmer potentiometers RT290 and RT390 (quiescent current) to min.
position (fully counterclockwise);
Variac set to min. (0 V
AC
);
Power switch to ON position.
4.4.1.3 A3: Powering Up
Visually check the PCB and the solder joints and repair, if necessary;
Check the mains voltage
230 V
AC
115 V
AC
Check or insert the primary fuse
T 0.8 A L 250 V T 1.6 A L 250 V
Connect the generator according to the
diagram;
Slowly increase the variac output
while checking the primary current
< 50 mA
AC
< 100 mA
AC
The green Power LED illuminates;
Increase the variac output until V1 is 64 V
AC
.
4.4.1.4 A3: Supply Voltages
Steps Generator Measurement
No. Description Id Value Test pos. Type Value Limits
1 Supply check G1 0 V V2 V
DC
–44 V
DC
±3 V
2 Supply check G1 0 V V3 V
DC
+44 V
DC
±3 V
3 IC supply check G1 0 V V4 V
DC
–17.4 V
DC
±0.6 V
4 IC supply check G1 0 V V5 V
DC
+17.4 V
DC
±0.6 V
