1.4 Technical Specifications (preliminary, subject to change without notice)
1.4.1 General
Inputs: AES/EBU: Impedance 110
W
typ.
Sensitivity min. 0.2 V
pp
Sampling rate 28...55 kHz
according to AES3 1992
Word clock: Impedance: hi-Z or 75
W
, selectable with internal jumper; TTL level
Outputs: AES/EBU: Impedance 110
W
typ.
Output level with 110
W
load: 5 V
pp
Sampling rate 28...55 kHz
according to AES3 1992
Word clock: Impedance: 75
W
, TTL level
Generator: Internal clock: 32; 44.1; 44.056; 48; 47.952 kHz
Accuracy: ±1 ppm
External clock: (if synchronized by an external video signal:
32; 44.1; 44.056; 48; 47.952 kHz
1.4.2 Power Supply
Mains voltage: 100...240 V
AC
, 50...60 Hz
Current consumption: 1...0.5 A
Power inlet: IEC 320/C14
1.4.3 Primary Fuse
Danger: The primary fuse is located inside the unit. Repair work may only be
performed by a trained service technician.
The primary fuse must be replaced by a spare fuse of exactly the same
type and value. The unit must not be opened by the user – risk of a
severe electric shock hazard.
Spare fuse: T 2.0 A H 250 V (5 × 20 mm) Order No. 51.01.1022
1.4.4 Operating Conditions
Ambient temperature: +10°...+40°C
Relative humidity: Class F (DIN 40040)
1.4.5 Safety and EMC Standards
Safety: Protection class I according to EN 60950:1992 + A1/A2:1993
(UL 1950)
EMC: Product family standard for audio, video, audio-visual, and entertain-
ment lighting control apparatus for professional use.
Emission: EN 55103-1:1996
Immunity: EN 55103-2:1996
