Studer RCC-02 Quick Guide

Studer Innotec SA
Quick guide RCC-02/-03
Quick guide V 6.1.0 11
Level
Nr
Xtender parameter description
Factory value
Inst.
1216
Program 4 (AUX 1)
Inst.
1217
Day of the week (AUX 1)
None days
Inst.
1218
Start hour (AUX 1)
07:00 hh:mm
Inst.
1219
End hour (AUX 1)
20:00 hh:mm
Inst.
1220
Program 5 (AUX 1)
Inst.
1221
Day of the week (AUX 1)
None days
Inst.
1222
Start hour (AUX 1)
07:00 hh:mm
Inst.
1223
End hour (AUX 1)
20:00 hh:mm
Expert
1269
Contact active with a fixed time schedule (AUX 1)
Expert
1270
Program 1 (AUX 1)
Expert
1271
Day of the week (AUX 1)
None days
Expert
1272
Start hour (AUX 1)
07:00 hh:mm
Expert
1273
End hour (AUX 1)
20:00 hh:mm
Expert
1274
Program 2 (AUX 1)
Expert
1275
Day of the week (AUX 1)
None days
Expert
1276
Start hour (AUX 1)
07:00 hh:mm
Expert
1277
End hour (AUX 1)
20:00 hh:mm
Expert
1278
Program 3 (AUX 1)
Expert
1279
Day of the week (AUX 1)
None days
Expert
1280
Start hour (AUX 1)
07:00 hh:mm
Expert
1281
End hour (AUX 1)
20:00 hh:mm
Expert
1455
Contact active on event (AUX 1)
Expert
1225
Xtender is OFF (AUX 1)
No
Expert
1518
Xtender ON (AUX 1)
No
Expert
1543
Remote entry (AUX 1)
No
Expert
1226
Battery undervoltage alarm (AUX 1)
No
Expert
1227
Battery overvoltage (AUX 1)
No
Expert
1228
Inverter overload (AUX 1)
No
Expert
1229
Overtemperature (AUX 1)
No
Expert
1520
No overtemperature (AUX 1)
No
Expert
1231
Active charger (AUX 1)
No
Expert
1232
Active inverter (AUX 1)
No
Expert
1233
Active Smart-Boost (AUX 1)
No
Expert
1234
AC input presence but with fault (AUX 1)
No
Expert
1235
AC input presence (AUX 1)
No
Expert
1236
Transfer relay ON (AUX 1)
No
Expert
1237
AC-Out presence (AUX 1)
No
Expert
1238
Bulk charge phase (AUX 1)
No
Expert
1239
Absorption phase (AUX 1)
No
Expert
1240
Equalization phase (AUX 1)
No
Expert
1242
Floating (AUX 1)
No
Expert
1243
Reduced floating (AUX 1)
No
Expert
1244
Periodic absorption (AUX 1)
No
Inst.
1601
AC-In energy quota (AUX1)
No
Expert
1245
Contact active according to battery voltage (AUX 1)
Expert
1288
Use dynamic compensation of battery level (AUX 1)
No
Expert
1246
Battery voltage 1 activate (AUX 1)
Yes
Expert
1247
Battery voltage 1 (AUX 1)
11.7/23.4/46.8 Vdc
